Mô tả sản phẩm

GENERAL FEATURES

The MCT NT is also available in the NT LIGHT configuration, that is, a CMM equipped with a light aluminum alloy Z spindle and x-axis "Single Read" system.

FEATURES AND BENEFITS

Main crossbar y made of light aluminum alloy for maximum rigidity and minimum moving mass
Silicon Carbide Z spindle: the use of this material ensures exceptional performance in terms of rigidity and thermal stability
Multi-sensor system for automatic compensation of errors due to thermal expansion of structural components.
"Dual Read" system on both X-spars, enables maintenance of excellent metrological performance up to cross sections of 2500 x 1800 mm
Spars (X-axis) with controlled expansion
Optical lines with high resolution free expansion system (0.1µm)
Can be equipped with a complete fairing and bellows system on the main movable structure (X / Y axes)

ENVIRONMENT

Temperature range for metrological specifications: Ambient temperature: 18 ÷ 22 °C Maximum hourly gradient: 1.0 °C/h Maximum daily gradient: 2.0 °C/24h Maximum gradient in volume: 1.0 °C/m
Operating temperature: 15 to 35 °C
Relative humidity for operation: 40 to 80 % (non-condensing)
Allowable vibration: (Peak/peak acceleration) 30 mm/s2 between 1 and 10 Hz 15 mm/s2 between 10 and 20 Hz 50 mm/s2 between 20 and 100 Hz

FEEDS

Pressure: 5.5 Bar
Air consumption: 150Nl/min
Power supply: 230 V ± 10%; 50 Hz ± 2% (single-phase) 115 V ±10%; 60 Hz ± 2% (single-phase)

MEASURING HEADS AND PROBES

Manual Heads: MIH, MH20, MH20i
Indexable Motorized Heads: PH10T, PH10M, PH10MQ, PH20, REVO
Point-to-point touchers: TP2, TP20, TP200
Analog keyers: SP25M
Laser Sensors: Perceptron Laser Scanner
Probe and tip changing systems: Automatic changing stations

PERFORMANCE

Each COORD3 CMM is tested according to UNI EN ISO 10360-2 standards. MCT-NT

The indicated performance is valid under the following conditions: - PH10M/PH10MQ/PH20/TP20/TP200: Ø4mm x stylus length20mm - PH10MQ/SP25: SM1, stylus Ø 5mm x 50mm - L= measurement length in mm - Ambient temperature conditions: T_:18÷22 °C; Gradients max: 1.0 °C/h - 2.0 °C/24h - 0.5 °C/m ^[1] Maximum Permissible Error on length measurements according to ISO 10360-2 ^[2] Maximum Permissible Error on Point Grip according to ISO 10360-2 ^[3] Maximum Permissible Error of Point Grip on scanning according to ISO 10360-4 for SP25M/SP80 probes. MCT NT LIGHT

The indicated performance is valid under the following conditions: - PH10M/PH10MQ/PH20/TP20/TP200: Ø4mm x stylus length20mm - L= measurement length in mm - Ambient temperature conditions: T_:18÷22 °C; Max gradients: 1.0 °C/h - 2.0 °C/24h - 0.5 °C/m ^[1] Maximum Permissible Error on length measurements according to ISO 10360-2 ^[2] Maximum Permissible Error on point taking according to ISO 10360-2 OPTIONS

Multi-wire wiring
Manual/automatic pallet loading/unloading system
PC and Printer
Training at Coord3 center or agents
Installation by Coord3 staff or agents
Models and dimensions: COORD3 MCT NT CMMs are available with the following measuring strokes (Y.Z mm): 20.10/20.15/25.18
