GENERAL FEATURES
The KRONOS series is also available in NT version, equipped with the innovative Silicon Carbide spindle for even higher metrological performance.
FEATURES AND BENEFITS
- Aluminum alloy moving carriage structure with integrated granite top
- Generously sized Z spindle made of light aluminum alloy or Silicon Carbide (NT)
- Mixed rack-and-pinion and hysteresis-free clutch drive system for smooth and repeatable movement
- Measurement system with high-resolution linear transducers (0.1 µm)
- Multi-sensor automatic temperature compensation system, with part temperature probe
ENVIRONMENT
- Temperature range for metrological specifications:
- T1:
Ambient temperature: 18 ÷ 22 °C
Maximum hourly gradient: 1.0 °C/h
Maximum daily gradient: 2.0 °C/24h
Maximum gradient in volume: 0.5 °C/m
- T2:
Room temperature: 16 ÷ 26 °C
Maximum hourly gradient: 1.0 °C/h
Maximum daily gradient: 5.0 °C/24h
Maximum gradient in volume: 1.0 °C/m
- Operating Temperature: 15 to 35 °C
- Relative humidity for operation: 40 to 80 % (non-condensing)
- Allowable vibration: (Peak/peak acceleration)
30 mm/s2between 1 and 10 Hz
15 mm/s2between 10 and 20 Hz
50 mm/s2between 20 and 100 Hz
FEEDS
- Pressure: 6 Bar -79PSI
- Air consumption: 160Nl/min
- Power supply: 230 V ± 10%; 50 Hz ± 2% single phase
- Absorption: 10A 1600W
MEASURING HEADS AND PROBES
- Manual Heads: MIH, MH20, MH20i
- Indexable Motorized Heads: PH10T, PH10M, PH10MQ
- Point-to-point touchers: TP2, TP20, TP200
- Analog keyers: SP25 scanning analog keyer
- Laser sensors: Metris LC/XC series (including qualification sphere)
- Probe and tip changing systems: Automatic changing stations
PERFORMANCE
Each COORD3 CMM is
tested according to UNI EN ISO 10360-2 standards.
KRONOS NT 20.15
The indicated performance is valid under the following conditions:
- PH10M/PH10MQ/PH20/TP20/TP200: Ø4mm stylus length 10mm
- PH10MQ/SP25: SM1, stylus Ø 5mm x 50mm
- L= measurement length in mm
- Ambient temperature conditions:
T1 : 18÷22°C; Max gradients: 1.0 °C/h - 2.0 °C/24h - 0.5 °C/m
T2: 16÷26°C; Gradients max: 1.0 °C/h - 5.0 °C/24h - 1.0 °C/m
[1] Maximum Permissible Error on length measurements according to ISO 10360-2
[2] Maximum Permissible Error on Point Grip according to ISO 10360-2
[3] Maximum Permissible Error of Point Grip on scanning according to ISO 10360-4 for SP25M/SP80 probes.
KRONOS NT 13.10 - 15.13
The indicated performance is valid under the following conditions:
- PH10M/PH10MQ/PH20/TP20/TP200: Ø4mm stylus length 10mm
- PH10MQ/SP25: SM1, stylus Ø 5mm x 50mm
- L= measurement length in mm
- Ambient temperature conditions:
T1 : 18÷22°C; Max gradients: 1.0 °C/h - 2.0 °C/24h - 0.5 °C/m
T2: 16÷26°C; Gradients max: 1.0 °C/h - 5.0 °C/24h - 1.0 °C/m
[1] Maximum Permissible Error on length measurements according to ISO 10360-2
[2] Maximum Permissible Error on Point Grip according to ISO 10360-2
[3] Maximum Permissible Error of Point Grip on scanning according to ISO 10360-4 for SP25M/SP80 probes.
OPTIONS
- Passive Antivibration System
- Active vibration damping system (AVM)
- Multi-wire wiring
- Manual/automatic pallet loading/unloading system
- PC and Printer
- Training at Coord3 center or agents
- Installation by Coord3 staff or agents
- Models and dimensions:
COORD3 KRONOS CMMs are available with the following measuring strokes (Y.Z mm):
13.10/15.13/20.15
