TOF Camera Femto Mega I

Danh mục:

Orbbec

Từ khóa:

3d vina , Camera Femto Mega I , Femto Mega I , hiệu chuẩn thiết bị , máy đo 2d , máy đo 3d , máy đo cmm , sửa máy đo , TOF Camera , TOF Camera Femto Mega I

Vận chuyển giao hàng toàn quốc

Phương thức thanh toán linh hoạt

Gọi ngay 0974.692.294 để mua và đặt hàng nhanh chóng

Mô tả sản phẩm

TOF Camera Femto Mega I Specification

Camera Specification	Physical Parameters
Depth technology: Time of flight	Data Connection: ethernet (M12 X-coding connector 8 pins)
Wavelength: 850nm	Power Input: PoE+/DC 12∼24V
Depth Range: *0.25-3.86m (depending on depth mode)	Trigger: Supported
Depth Resolution/FPS: Snapshot Mode: Up to 1024X1024@10fps (WFOV), 640X576@10fps (NFOV)Stream Mode: Up to 1024X1024@15fps (WFOV), 640X576@30fps (NFOV)	Power Consumption: Average <11W
Depth FOV: H 120º V 120º (WFOV), H 75º V 65º (NFOV)	Operating Environment: 0ºC-45ºC; Indoor/Semi-outdoor; 8-90%RH (non-condensing)
RBG Resolution/FPS: Snapshot Modo: up to 3840X2160@3fps, 1920X1080@10FPSStream; Mode: Up to 3840X2160225fps, 1920X1080@30FPS	SDK Support: Orbbec Industry SDK
RGB FOV: H 80º V 51º	Data Output: Point Cloud, Depth Map, IR&RGB
Processing: NVIDIA Jetson Nano	*Dimensions (WHD):* 180mm×50mm×110mm
IMU: Supported	Weight: 1080g
Depth typical systematic error (accuracy) <11mm+0.1% distance; Depth random error std. dev.(precision)* ≤ 17 mm	Installation: 8×M5

TOF Camera Femto Mega I Applications

Depalleztization: The camera can capture spatial information about objects on a pallet. By indentifying the exact location, orientation, and shape of each item, Femto Mega I enables precise robotic picking

Loading and Unloading: The camera Provides accurate distance measurements allowing for precise robotic handling. This depth information minimizes cp;;isions and errors, optimingzing effciency and reducing damage to goods in logistics and manufacturing environments

Large object Dimensioning The camera enables automated dimensioning of large objects on a moving production line. It enables precise volume estimation, better cost calculation, and the possibility to sort out oversized objects
