Stereo Vision Camera Genmini 2 L is easy to set up and operate with the Orbbec SDK, and the camera delivers extremely accurate and reliable data in various lighting condition from pitch black to semi-outdoor

Global shutter for RGB and IR cameras
Wide Field of View at 91° Horizontal and 66° Vertical
High Quality depth data output from 0.25m to 10m
up to 30 fps at 1280X800 depth resolution
USB Type-C for power and data connectivity
IMU supported
Multi-camera synchronization

Gemini 2 L Specification

Camera specifications	Physiccal Parameters
Depth Technology: Active stereo IR	Data Connection: USB 3.0 & USB 2.0
Wavelength: 850nm	Power input: DC 5V ≥2.0A
Depth Range: 0.2-10m	Trigger: Supported
Depth Resolution/FPS: Up to 1280X800@60fps	Power Consumption: Typical average <3.0W/Max peak value <10.0W
Depth FOV: H91° V66°	Operating Environment: 0°C-40°C, 8%RH- 90%RH (non-condensing), Indoor/Semi-Outdoor
RGB Resolution/FPS: Up to 1280X800@60fps	SDK Support: Orbbec SDK
Processing: Orbbec ASIC	Data output: Point Cloud, Depth Map, IR&RGB
IMU: Supported	*Dimensions(WHD):* 124mm × 29mm × 26 mm ± 0.5mm
*Precision: ≤2% @ 4m	Weight:152±2g
	Installation: 1 × ¼−20 UNC thread mounting point 2 × M3 Thread mounting points

Gemini 2 L Applications AMR: Real-time 3D mapping and navigation capabilities with advanced object detection and avoidance Cobot: A depth camera enables Collaborative Robots (Cobot) to respond to human commands, gestures and interact safely with human intuitively. Assembly: Avanced 3D data capture and analysis is enabling automated assembly processes with high precesion, reducing errors and increasing overall productivity
