Mô tả sản phẩm

GENERAL FEATURES

FEATURES AND BENEFITS

Generous pad spacing sizing for optimal mechanical rigidity
High-rigidity Y main crossbar with unique tubular steel design
Z spindle made of extruded aluminum alloy provides rigidity and minimizes the moment of inertia.
X-beams with large cross-sectional area made of stabilized steel and equipped with support system that allow linear expansion without induced deformation
High-strength epoxy resin X/Y axis slideways ground (roughness 0.4 mm)
Measuring system with high-resolution (0.1µm) linear transducers with "Dual Reader" system on longitudinal X axis
"Dual Drive" system on longitudinal X axis (optional, standard for Y=3000 stroke)
Multi-sensor system for automatic compensation of errors due to thermal expansion of structural components.

ENVIRONMENT

Temperature range for metrological specifications: Ambient temperature: 18 ÷ 22 °C Maximum hourly gradient: 1.0 °K/h Maximum daily gradient: 2.0 °K/24h Maximum gradient in volume: 0.5 °K/m (SL NT) - 1.0 °K (SL)
Operating temperature: 15 to 35 °C
Relative humidity for operation: 40 to 80 % (non-condensing)
Allowable vibration: (Peak/peak acceleration) 30 mm/s2 between 1 and 10 Hz 15 mm/s2 between 10 and 20 Hz 50 mm/s2 between 20 and 100 Hz

FEEDS

Pressure: 6 Bar
Air consumption: maximum 300 Nl/min
Power supply: 230 V ± 10%; 50 Hz ± 2% (single-phase) 115 V ±10%; 60 Hz ± 2% (single-phase)

MEASURING HEADS AND PROBES

Manual Heads: MIH, MH20, MH20i
Motorized Heads: PH10M, PH10MQ
Indexable Motorized Heads: PH20, REVO
Point-to-point touchers: TP2, TP20, TP200
Analog keyers: SP600, SP25M, SP80
Probe and tip changing systems: Automatic changing stations

PERFORMANCE

Each COORD3 CMM is tested according to UNI EN ISO 10360-2 standards. MCT STARLIGHT

The indicated performance is valid under the following conditions: - TP2/TP20-5W/TP200: Ø4mm x stylus length 10mm - SP25: SM1, stylus length 50mm Ø5mm - REVO: RSP2/RSH175 - RSP3-1/SH25-1, stylus length 20mm - SP80: Ø 5mm stylus length 50mm - L= measurement length in mm - Ambient temperature conditions: T_:18÷22 °C; Gradients max: 1.0 °C/h - 2.0 °C/24h - 1.0 °C/m ^[1] Maximum Permissible Error on length measurements according to ISO 10360-2 ^[2] Maximum Permissible Error on Point Grip according to ISO 10360-2 ^[3] Maximum Permissible Error of Point Grip on scanning according to ISO 10360-4 for SP25M/SP80/REVO probes. MCT STARLIGHT NT

The indicated performance is valid under the following conditions: - TP2/TP20-5W/TP200: Ø4mm x stylus length 10mm - SP25: SM1, stylus length 50mm Ø5mm - REVO: RSP2/RSH175 - RSP3-1/SH25-1, stylus length 20mm - SP80: SM1, Ø 5mm stylus length 50mm - L= measurement length in mm - Ambient temperature conditions: T_:18÷22 °C; Gradients max: 1.0 °C/h - 2.0 °C/24h - 0.5 °C/m ^[1] Maximum Permissible Error on length measurements according to ISO 10360-2 ^[2] Maximum Permissible Error on Point Grip according to ISO 10360-2 ^[3] Maximum Permissible Error of Point Grip on scanning according to ISO 10360-4 for SP25M/SP80/REVO probes. OPTIONS
