Sửa chữa tủ nhiệt độ và độ ẩm YTHG-072 YTHG-162

Danh mục:

Từ khóa:

3d vina , hiệu chuẩn , hiệu chuẩn thiết bị , máy đo 2d , máy đo 3d , máy đo cmm , sửa máy đo 2d , sửa máy đo 3d , sửa máy đo cmm

Vận chuyển giao hàng toàn quốc

Phương thức thanh toán linh hoạt

Gọi ngay 0974.692.294 để mua và đặt hàng nhanh chóng

Mô tả sản phẩm

Model	YTHG-072	YTHG-162
Inner chamber size(cm)	45×40×40	60×45×60
Exterior chamber size (cm)	100x200x170	120x215x185
Testing temperature range	-70℃，-60℃, -40℃, -20℃, 0℃~150℃，other temperature can be customized
Testing humidity range	20%RH～98%RH(low humidity10%RH～98%RH或5%RH～98%RH can be customized)
Temp.humi.fluctuation	±0.3℃；±0.5%RH
Temp.humi.uniformity	±1.5℃；±3%RH (empty loading after stabilizing for 30 mins)
Temp.humi.resolution	0.01℃；0.1%RH
Heating&cooling time ℃/min	Heat-up:3℃/min(average),cool-down:1℃/min(average)
Exterior chamber material	Cold-rolled plate + Powder coating
Interior chamber material	SUS#304 Stainless steel
Insulation material	PU+ fiberglass wool
Circulation system	Centrifugal fan air circulation system
Heating system	SUS# Stainless steel high-speed heater
Humidification system	Electrothermal steam humidification
Dehumidifying	ADP critical dew point cooling / dehumidifying method
Refrigeration system	Compressor + Finned evaporator + Air(Water) cooled condenser
Controlling system	Touch screen controller+SSR+PID
Other components	Vacuum glass observation window
	Test hole (50mm)
	Control status indicator
	Interior light
	Compartment shelf (2 freely adjustable)
Safety protection device	Humidification system overheat protection
	Compressor overload protection
	Control system overload protection
	Overload indicator
	Phase sequence protection
	Water shortage protection
	High voltage and low voltage protection
	Over-temperature protection
	Water supply delay protection
	Fan overcurrent protection
Power supply	AC 1Ψ 220V; 3Ψ380V 60/50Hz
Customization service	Non-standard or special requirements are all welcome
