The MIT2500 high voltage handheld insulation and continuity tester has been designed for motor and cable testing, specialist applications, and electrical testing applications, where operation voltages exceed 1000 V and higher insulation test voltages are needed.
The MIT2500 offers both fixed range voltages of 50 V, 100V, 250 V, 500 V, 1000 V, and 2500 V, as well as a variable range that allows any voltage between 50 V and 2500 V to be 'dialled in'. This is supported by the new test voltage feedback control, which maintains the output test voltage to within 2 % of the selected range, even when under test. The feedback-controlled insulation test voltage is now accurate to +2 % -0 % compared to the original +20 %, providing a more accurate test voltage without the risk of overvoltage damage to circuits. A variable range allows the exact test voltage to be selected from 50 V to 999 V in 1 V steps, (1 kV to 2.5 kV in 10 V steps) providing 1100 test voltage options.
The MIT2500 uses a redesigned case, back-stand, and six cell battery compartment, as well as incorporating a guard terminal to reduce surface leakage currents that reduce accuracy at higher voltages. All instruments are over-molded for increased protection and have an IP54 weatherproof rating.
- Designed for Motor and Cable Testing, Specialist Applications and Electrical Testing Markets
- Insulation Testing to 2.50 Kv (New)
- 200 GΩ Measurement Range at ≥ 1.00kv
- Guard Terminal for Testing of Equipment With High Surface Leakage Issues
- Stabilized Insulation Test Voltage to -0% +2% +/-2V
- Variable Insulation Test Voltage from 50V to 999 V in 1V Steps
- Variable Insulation Test Voltage from 1.00 Kv to 2.50kv in 10V Steps
- Single Range, Fast Continuity Testing from 0.01Ω to 1MΩ
- 0.01mv to 600V TRMS AC and DC Voltage Measurement
- Test Result Storage and Bluetooth Downloading
- Live Circuit Detection and Protection
- CATIV 600V Applications & IP54 Environmental Protection
- Rechargeable Options for Mains and Car Charging
