Mô tả sản phẩm

HDMI Output

View Your Inspection On Your HD Monitor. Reduce Eye Strain And Neck Fatigue.

This innovative digital microscope connects directly to a monitor through an HDMI output, allowing operators to view high quality images while looking straight ahead at a large screen in a comfortable posture. ZEN Mount is a stable and highly versatile lightweight, multi-angle, telescoping mount that offers optimal maneuverability. The ball joint at the base of the mount provides limitless positioning options. A second ball joint at the top can also be angled to virtually any position. The ZEN Mount features a telescoping arm, with an extended reach of 12"-16".

Designed For Versatility

By loosening the twist lock, the Zen arm can achieve a reach of 12" - 16"

The ball joint rotates 360 degrees, an ideal feature for applications that require multiple inspection angles.

The ZEN Mount can be stationed at nearly any angle, providing limitless positioning options This feature also makes it easy to place the stand out of the way when not in use, saving valuable work space.

HDMI Output

View crystal clear HD images in 1080p resolution. [embed]https://youtu.be/o-rIqZQ0Iow[/embed]

Features

2-megapixel sensor
HDMI output
LED illumination with intensity control
Large magnification range and long working distance
Infrared remote control for all major features
The ZEN Mount is designed for versatility. Inspect from nearly any angle
Twist lock is used to adjust the reach, arm position, and ball joint angle
Takes up minimum work space and can be positioned out of the way when not in use
Includes a heavy-duty metal adjustable table clamp: up to 3"; opening

Weight	3.55 lbs
Dimensions	15.2 × 8.34 × 2.5 in
Item #	26700-401-413
Image Sensor	1/3” Color CMOS
Effective Pixels	2M
Signal Output	HDMI 1920 x 1080
Video Format	AVI
Frames Per Second	60fps
Magnification	See Magnification Tables
Gain Control	Automatic
Snap Shot Mode	Via Remote Control
White Balance	Manual and Automatic
Power Consumption	0.225A(MAX)
Power Source	DC 5V/2A input; Cable length 180cm
LED Lighting	30 White LEDs with brightness & sector control
