ĐỒNG HỒ SO ĐIỆN TỬ 543-590B 25,4MM ; 0,001MM

Danh mục:

Dụng cụ đo Mitutoyo

Từ khóa:

3d vina , 543-590B , hiệu chuẩn , hiệu chuẩn thiết bị , máy đo 2d , máy đo 3d , máy đo cmm , sửa máy đo 2d , sửa máy đo 3d , sửa máy đo cmm

Vận chuyển giao hàng toàn quốc

Phương thức thanh toán linh hoạt

Gọi ngay 0974.692.294 để mua và đặt hàng nhanh chóng

Mô tả sản phẩm

Đồng hồ so điện tử 543-590B

Thông số kỹ thuật đồng hồ so 543-590B

Range:	25,4 mm
Digital step:	0,001 mm
Max. Permissible Error (Total Range):	0,003 mm
Hysteresis:	0,002 mm
H MPE (Hysteresis):	0,002 mm
Repeatability:	0,002 mm
Inch-Metric:	Metric
Type:	EN ISO Standard
Mass:	190 g
Data output:	Yes
Measuring force:	≤1,8 N N
Scale:	Capacitance type, ABSOLUTE linear encoder
Max. response speed:	Unlimited
Stem Ø:	8 mm
Contact point:	Carbide ball, thread M 2.5 x 0.45 mm
Alarm:	Low voltage, ABS composition error, overflow error, tolerance limit setting error
Power supply:	1 battery CR-2032
Battery life:	Standard mode: approx. 1 year fast mode: approx. 4.5 month
Display:	LCD, character height 8 mm, rotatable 330°
Protection:	IP42
Max. response speed:	Unlimited
Measurement frequency (MAX/MIN/RANGE):	Standard mode: 10 times/s fast mode: 50 times/s (plunger speed max. 50 µm/s for peak measurement)
Delivered:	Including 1 battery
Low voltage alarm:	Yes
ZERO/ABS:	Yes
GO/±NG judgement:	Yes
Digimatic data output:	Yes
ON/OFF:	Yes
DATA (output with cable) / HOLD (display value):	Yes
MAX/MIN/RANGE:	Yes
Lock function:	Yes
Selectable resolution:	Yes
Fast measurement mode:	yes
Calculation function (with formula):	Yes
PRESET 3x:	Yes
Analog bar resolution switchable:	Yes
Function lock:	Yes
Power supply report:	UN 38.3 Test Summary Report
Digital/Analog:	Digital

This indicator allows you to use a calculation function for the measured value Ax+B+Cx^-1

The integrated calculation formula is useful in a variety of applications (e.g. roll diameter measurement)
Coefficients A,B and C are freely definable. X = displacement of the plunger
Analogue bar graph in the display (14 different scales switchable)
GO/±NG tolerance judgement function
MAX/MIN/RANGE function to measure peak values
A fast measurement frequency mode(detection cycle 20 ms or 50 times/s) is selectable to measure in the peak detection mode (MAX/MIN/RANGE) more reliably
Easy indicator setup via a setup menu
A USB interface box can be used to set up the indicator from PC via dedicated software

Catalogue: 543-590B
